| Output | DC Voltage | DC 12V |
| Rated Current | 2.2A | |
| Current Range | 0.~2.2A | |
| Rated Power | 30W | |
| Efficiency | 88% | |
| Voltage Tolerance Note.3 | - | |
| Line Regulation | ±1.0% | |
| Load Regulation | ±2.0% | |
| Setup, Rise Time | 1500ms, 30ms/220VAC | |
| Hold Up Time (Typ) | 20ms/220VAC at full load | |
| Input | DC Voltage | 180-220VAC |
| Frequency Range | 50 ~ 60Hz | |
| Power Factor | > 0.5 | |
| AC Current | 0.25A (MAX) | |
| Inrush Current (Typ.) | Cold Start 40A (width = 200㎲ measured at 50% Ipeak) at 220VAC | |
| Protection | Over Load | Above 110% rated output power |
| Protection type : Hiccup mode, recovers automatically after fault condition is removed | ||
| Over Voltage | Protection type : Shut off o/p voltage, clamping by zener diode | |
| Over Temperature | Shut down, recovers automatically after temperature goes down | |
| Enviroment | Working Temperature | -20~+50℃ (Refer to "Derating Curve") |
| Working Humidity | 20~90% RH non-condensing | |
| Storage Temperature. Humidity | -40~+80℃, 10~95% RH | |
| Temperature. Coefficient | ±0.03%/℃ (0~50℃) | |
| Vibration | 10~500Hz, 2g 10min./1cycle, period for 60min. each along X,Y,Z axes. | |
| Safety & EMC | Safety Standards | IP68 |
| Withstand Voltage | I/P-O/P : 3.75KVAC | |
| Isolation Resistance | I/P-O/P : ＞100M Ohms/ 500VDC/ 25℃/ 70% RH | |
| Others | Dimension | 27 X 182 X 18.5 mmH |
| Weight | 65g | |
| Note | All parameters NOT specially mentioned are measured all 220VAC input, rated load and 25℃ of ambient temperature. | |
| Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire teminated with a 0.1uF & 47uF parallel capacitor. | ||
| Tolerance : includes set up tolerance, line regulation and load regulation. | ||
| Suitable for indoor use or outdoor use without direct sunlight exposure. | ||
